Description
Specifications:
KV…………………………………….380
Configuration……………………18N24P
Stator Diameter……………….40mm
Stator Length…………………..6mm
Shaft Diameter…………………4mm
Motor Dimension(Dia.*Len)………………..Φ44.35×21mm
Weight(g)………………………..66g
ldle current(10)@10v(A)……………….0.3A
No.of Cells(Lipo)…………………………..4-6S
Max Continuous current(A)180S…………………16A
Max Continuous Power(W)180S…………………………..380W
Max. efficiency current………………………..(2-5A)>92%
internal resistance……………………194mΩ
internal resistance……………………194mΩ
