Full Carbon Fiber Folding Hexa Frame – ZD850

Description

Product description:

Arm with upturned 5 ° force to play to the extreme, larger diameter 20mm carbon tube.
Aluminum Folding, Nylon Clamp (Tightened Clamp) 8 hole motor mount, compatible with more motors.
Motor Block Diagonal wheelbase of about 850mm, maximum support 16-inch paddle.
Center plate size 245mm * 180mm more space, the middle plate height of about 35mm.
Hook head with 10 * 330mm long carbon tube, can be free to stretch the length you want, with the porous bit PTZ board.
Tripod with a diameter of 16mm carbon tube, height 350mm, tripod crossbar 500mm, more stable grounding area.
Tripod with double-tube carbon fiber as support, bear the force of more than 50kg.

Parameter:

• 20mm carbon tube arm
• 16mm + 10mm carbon tube tripod
• 3.0 mm botton center plate
• 1.5mm upper center plate
• Aluminum alloy folding pieces
• Nylon mixed carbon pipe clamp
• Plastic tripod connection (force 50kg)
• The net weight of frame kit  is about 1210g

Recommended items(not included):

• 3508-380kv motor
• 6s 22.2v 25c Lithium battery
• 1555/1547 15 inch cw ccw props
