Description
Main Features:
Flight Controller
1. Built-in inertial sensors for the measurement of aircraft attitude and built-in pressure sensor for the detection of aircraft altitude.
2. Support for multiple receiver types. If used with the DJI Datalink 3, the A3-AG has direct access to features in the DJI MG app such as intellignt planning and operation.
3. M1 to M8 are used to connect the ESCs of the aircraft and iESC for DJI Intelligent ESC
communication.
GNSS-Compass Module
The GNSS-Compass module has a built-in GPS/GLONASS and compass. The compass is used
for geomagnetic field measurements.
PMU Module
Supported the LiPo batteries. with built-in PMU providing power for the whole Flight Control
System and low voltage protection function.
LED Module
The LED Module has an integrated LED Indicator and Micro USB port.
A. The LED is mainly for flight control system status indication during flight (e.g. Flight Mode).
B. In addition, there is a Micro USB port for firmware upgrades via DJI Assistant 2.
| Specifications | |
| Support Airframes | 4-rotor: I4, X4 6-rotor: I6, V6, Y6, IY6 8-rotor: X8, I8, V8, IX8 |
| Supported ESC output | 400 Hz refresh frequency |
| Supported Receivers | DJI Datalink 3 DJI DR16 S-Bus |
| Recommended Batteries | 3S-12S LiPo battery |
| Required Operation System | Windows 7, 8 or later Mac OS X 10.11 or later |
| Rated Power | 5 W |
| Rated Peak Power | 8 W |
| Input Voltage Range | 10.5 ¨C 52 V |
| Static Electricity | AD: ±8 kV CD: ±4 kV |
| Operating Temperature | 14° to 131° F (-10° to 55° C) |
| Weight | Flight Controller: 66 g GPS-Compass Pro: 60 g LED Module: 15 g PMU: 45 g IMU Pro: 40 g |
| Dimensions | Flight Controller: 64 mm x 42 mm x 19.5 mm GPS-Compass Pro: 61 mm (diameter) x 13 mm LED Module: 27 mm x 27 mm x 8 mm IMU Pro: 34 mm x 26.5 mm x 20 mm PMU: 51 mm x 34 mm x 13.5 mm |
NOTE :- It comes without box.
